RUIDE GPS GNSS Receiver 1598 Channels RUIDE R93I Pro GNSS Receiver Base and Rover Survey Equipment

Product Categories
Chengdu Jiebo Technology Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap RUIDE GPS GNSS Receiver 1598 Channels RUIDE R93I Pro GNSS Receiver Base and Rover Survey Equipment from wholesalers

    Buy cheap RUIDE GPS GNSS Receiver 1598 Channels RUIDE R93I Pro GNSS Receiver Base and Rover Survey Equipment from wholesalers
    • Buy cheap RUIDE GPS GNSS Receiver 1598 Channels RUIDE R93I Pro GNSS Receiver Base and Rover Survey Equipment from wholesalers
    • Buy cheap RUIDE GPS GNSS Receiver 1598 Channels RUIDE R93I Pro GNSS Receiver Base and Rover Survey Equipment from wholesalers
    • Buy cheap RUIDE GPS GNSS Receiver 1598 Channels RUIDE R93I Pro GNSS Receiver Base and Rover Survey Equipment from wholesalers
    • Buy cheap RUIDE GPS GNSS Receiver 1598 Channels RUIDE R93I Pro GNSS Receiver Base and Rover Survey Equipment from wholesalers
    • Buy cheap RUIDE GPS GNSS Receiver 1598 Channels RUIDE R93I Pro GNSS Receiver Base and Rover Survey Equipment from wholesalers

    RUIDE GPS GNSS Receiver 1598 Channels RUIDE R93I Pro GNSS Receiver Base and Rover Survey Equipment

    Ask Lasest Price
    Brand Name : RUIDE
    Model Number : R93I Pro
    Price : $2,700.00
    Payment Terms : L/C, T/T
    Supply Ability : 1 ~ 30 day
    Delivery Time : 30 work day
    • Product Details
    • Company Profile

    RUIDE GPS GNSS Receiver 1598 Channels RUIDE R93I Pro GNSS Receiver Base and Rover Survey Equipment

    RUIDE GPS GNSS Receiver 1598 Channels RUIDE R93I ProGNSS Receiver Base and Rover Survey Equipment

    Overview

    Product Description
    Ruide R93i Pro


    GNSSconfiguration
    Number of channels
    1598
    BDS
    B1I,B2I,B3I, B1I,B3I,B1C,B2a,B2b
    GPS
    L1C/A,L2P,L2C,L5,L1C*
    GLONASS
    G1,G2,G3*
    GALILEO
    E1,E5b,E5a,E5 AltBoc*,E6c*
    QZSS
    L1 ,L2C, L5/ IRNSS:L5*/ SBAS:L1C/A,L5*
    Positioning output rate
    1Hz~20Hz
    Differential support
    CMR,RTCM2.X,RTCM3.0,RTCM3.2
    Static format support
    GNS, Rinex dual format static data


    RTK positioning accuracy
    Plane: ±(8+1×10-6D) mm (D is the distance between the measured points) Elevation: ±(15+1×10-6D) mm
    (D is the distance between the measured points)


    Static positioning accuracy
    Plane: ±(2.5+0.5×10¯6D) mm (D is the distance between the measured points)
    Elevation: ±(5+0.5×10¯6D) mm
    (D is the distance between the measured points)
    DGPS positioning accuracy
    Plane accuracy: ±0.25m+1ppm;Elevation accuracy: ±0.50m+1ppm
    Initialization time
    <10 seconds
    Initialization reliability
    ＞99.99%
    IMU tilt compensation
    Additional horizontal pole tip uncertainty typically less than 10mm + 0.7 mm/° tilt down to 30°
    IMU tilt angle:0°~60°


    communication


    NFC Communication
    Realizing close range (shorter than 10cm) automatic pair between receiver and controller (controller equipped NFC wireless
    communication module needed)
    WiFi
    802.11b/g access point and client mode, can provide WiFi hotspot service
    Bluetooth
    BLEBluetooth 4.0 standard, support for android, ios cellphone connection
    Wireless modem
    Built-in radio, typically work range can be 8KM Radio repeater
    I/O port
    5PIN LEMO external power port + RS232, 1 radio antenna interface, Type C , Micro SIM card
    frequency band:
    410-470MHz
    Protocol
    SOUTH,Farlink,TrimTalk,ZHD, HUACE


    User Interface
    Buttons
    One button operation
    Indicators
    Four indicate lights


    Electrical physical properties
    battery
    Internal Li-on, 6800mAh, 7.4V
    Power Supply
    9-25V DC, overvoltage protection
    size
    135mm(Diameter)x84.75mm(Height)
    weight
    0.97kg (battery included)
    material
    Magnesium aluminum alloy shell


    Environmental characteristics
    Dust and water release
    IP68 standard, protected from long time immersion to depth of 1m
    Storag
    -55°C~+85°C
    Operating
    -45℃~70℃
    Specification


    System
    model
    H6
    operating system
    Android 8.1
    CPU
    2.0 GHz eight-core processor
    Memory
    3GB RAM
    Storage
    32GB


    Communication
    Network
    TDD/FDD-LTE 4G
    WiFi
    802.11b/g access point and client mode, can provide WiFi hotspot service
    Bluetooth
    V2.1+EDR/V3.0+HS/V4.1
    NFC
    Support NFC IGRS
    USB
    Mini USB, supports OTG


    Electrical
    Battery
    7.4V, 3400mAh
    Battery life
    12 hours
    Charging
    < 4 hrs for full charge


    Physical
    size
    206mm×85mm×40mm
    Weight
    520g
    Operating temperature
    -30℃ ~ +60℃

    RUIDE GPS GNSS Receiver 1598 Channels RUIDE R93I Pro GNSS Receiver Base and Rover Survey Equipment
    RUIDE GPS GNSS Receiver 1598 Channels RUIDE R93I Pro GNSS Receiver Base and Rover Survey Equipment
    RUIDE GPS GNSS Receiver 1598 Channels RUIDE R93I Pro GNSS Receiver Base and Rover Survey Equipment
    Data Collector
    RUIDE GPS GNSS Receiver 1598 Channels RUIDE R93I Pro GNSS Receiver Base and Rover Survey Equipment

    WHY CHOOSE US

    RUIDE GPS GNSS Receiver 1598 Channels RUIDE R93I Pro GNSS Receiver Base and Rover Survey Equipment
    GEODETSKOJ ŠKOLI SPLIT isporučujemo STONEX totalne stanice, teodolite i GNSS prijemnike
    Geodetske škole imaju ključnu ulogu u pružanju učenicima potrebnog znanja i vještina u području geodezije.Integracija najnovijih
    geodetskih instrumenata u takve obrazovne ustanové može značajno poboljšati iskustvo učenika i bolje ih pripremiti za primjenu u
    stvarnom svijetu.Najnoviji geodetski instrumenti nude napredne značajke i mogućnosti koje mogu pružiti studentima intenzivnije
    iskustvo učenja.Korištenjem ovih instrumenata, studenti mogu steći praktično iskustvo u prikupljanju podataka, analizi itumačenju, što su ključne vještine u području geodezije.
    U suradnji sa STONEX S.r.l. Italija, geodetskoj školi u Splitu isporučili smo najnovije totalne stanice, teodolite i GNSS prijemnike.
    RUIDE GPS GNSS Receiver 1598 Channels RUIDE R93I Pro GNSS Receiver Base and Rover Survey Equipment
    RUIDE GPS GNSS Receiver 1598 Channels RUIDE R93I Pro GNSS Receiver Base and Rover Survey Equipment
    Customer Photos
    RUIDE GPS GNSS Receiver 1598 Channels RUIDE R93I Pro GNSS Receiver Base and Rover Survey Equipment
    RUIDE GPS GNSS Receiver 1598 Channels RUIDE R93I Pro GNSS Receiver Base and Rover Survey Equipment
    Certifications
    RUIDE GPS GNSS Receiver 1598 Channels RUIDE R93I Pro GNSS Receiver Base and Rover Survey Equipment
    RUIDE GPS GNSS Receiver 1598 Channels RUIDE R93I Pro GNSS Receiver Base and Rover Survey Equipment
    Company Profile
    RUIDE GPS GNSS Receiver 1598 Channels RUIDE R93I Pro GNSS Receiver Base and Rover Survey Equipment

    FAQ

    1. who are we?
    We are based in sichuan, China, start from 2016,sell to Africa(30.00%),Southeast Asia(16.00%),Mid East(11.00%),Eastern
    Asia(10.00%),South America(10.00%),Central America(5.00%),South Asia(5.00%),Southern Europe(5.00%),North America(4.00%),Eastern
    Europe(4.00%). There are total about 11-20 people in our office.

    2. how can we guarantee quality?
    Always a pre-production sample before mass production;
    Always final Inspection before shipment;

    3.what can you buy from us?
    GNSS RTK,Total station,Level,Survey accessory,laser rangefinder

    4. why should you buy from us not from other suppliers?
    1.More than 20 years of experience in the trade field. 2.All products will have been strictly quality checked in factory before
    sending out and all products have one year warranty.

    5. what services can we provide?
    Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES；
    Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
    Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
    Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian

    Our Service
    RUIDE GPS GNSS Receiver 1598 Channels RUIDE R93I Pro GNSS Receiver Base and Rover Survey Equipment
    Packing & Delivery
    RUIDE GPS GNSS Receiver 1598 Channels RUIDE R93I Pro GNSS Receiver Base and Rover Survey Equipment
