2'' Accuracy Robotic Total Station Surveying Equipment R3 Stonex ODM

Ask Lasest Price
Brand Name :	Stonex
Model Number :	R3
Price :	＄1,200.00
Payment Terms :	T/T, L/C
Delivery Time :	30 work day

Add to Cart

Product Details
Company Profile

2'' Accuracy Robotic Total Station Surveying Equipment R3 Stonex ODM

Product Description

Surveying instrument 2'' accuracy total station color screen R3 total station stonex

* Long measuring distance (800 meters without prism)
Using digital phase laser ranging technology, it can achieve high-precision measurement of long-distance targets in prism-free mode, ranging up to 800 meters; single prism 3500 meters.

* Fast measure speed
Equipped with a new fast digital ranging lens and applying a new ranging technology, it can achieve a single precise measurement of 0.8' and a tracking of 0.3', effectively ensuring the measurement efficiency.

*One-click measurement
When the instrument is measuring, the eye does not need to leave the telescope, and the measurement can be completed with one key. One-key measurement has little impact on measurement operations and can ensure the accuracy of measurement work.

*Dual axis compensation
The fully automatic dual-axis compensator, combined with the visual display of the electronic bubbles, can achieve precise leveling and ensure the accuracy of the horizontal position. 2'' Accuracy Robotic Total Station Surveying Equipment R3 Stonex ODM

2'' Accuracy Robotic Total Station Surveying Equipment R3 Stonex ODM

Specification

Optical Instruments Dual-axis 2'' Accuracy Reflectorless 800m R3 Stonex Total Station
telescope	Imaging	Erect
	Magnification	30×
	Lens tube length	160mm
	Resolution	2.8″
	Field of view	1°30'
	Effective aperture	44mm
Angle measurement part	Angle measurement method	Absolute coding system
	Accuracy	2''
	Minimum display reading	1"
	Display unit	360° / 400 gon / 6400 mil
Ranging part	Ranging light source	650~690nm
	measure time	0.5s (quick test)
	Spot diameter	12mm×24mm (at 50m)
	Laser pointing	Switchable laser pointer
	Laser class	Class 3
	No prism	800 m
	Single prism	3500 m
	Prism accuracy	2mm+2×10 -6×D
	Prism-free accuracy	3mm+2×10-6 ×D
	Prism constant correction	-99.9mm +99.9mm
	Minimum reading	Precision measurement mode 1 mm Tracking measurement mode 10 mm
	Temperature setting range	−40℃+60℃
	temperature range	Step size 1℃
	Atmospheric pressure correction	500 hPa-1500 hPa
	Atmospheric pressure	Step length 1hPa
Level	Long level	30″/ 2 mm
Level	Circular level	8′ / 2 mm
Laser plummet	wavelength	635 nm
	Laser class	Class 2
	Precision	±1.5 mm / 1.5m
	Spot size/energy	Adjustable
	Maximum output power	0.7 -1.0 mW, adjustable through software switch
Compensator	Compensation method	Dual axis compensation
	Compensation method	Graphical
	The scope of work	±4′
	Resolution	1"
Onboard battery	power supply	lithium battery
	Voltage	DC 7.4V
	operating hours	About 20 h (25℃, measurement + distance measurement, interval 30s), only when measuring angle> 24 h
Display/Button	Types of	2.8 inch color screen
	illumination	LCD backlight
	button	Full numeric keyboard
data transmission	Interface Type	USB interface
data transmission	Blue tooth transmission	stand by
Environmental indicators	Operating temperature	-20℃ - 50℃
	storage temperature	-40℃ - 60℃
	Waterproof and dustproof	IP 54
