    IMU Tilt CHC E93 Gnss Rtk Receiver 936 Channels antenna Surveying And Mapping Instrument

    Ask Lasest Price
    Brand Name : CHCNAV
    Model Number : E93
    Price : $2,900.00
    Payment Terms : L/C, T/T
    Supply Ability : 1 ~ 30 day
    Delivery Time : 30 work day
    • Product Details
    • Company Profile

    IMU Tilt CHC E93 Gnss Rtk Receiver 936 Channels antenna Surveying And Mapping Instrument

    IMU Tilt CHC Gps Rtk receiver 936 channels Surveying and Mapping Instrument E93 Gnss

    IMU Tilt CHC E93 Gnss Rtk Receiver 936 Channels antenna Surveying And Mapping Instrument

    IMU Tilt CHC E93 Gnss Rtk Receiver 936 Channels antenna Surveying And Mapping Instrument

    IMU Tilt CHC E93 Gnss Rtk Receiver 936 Channels antenna Surveying And Mapping Instrument

    Technical Parameters

    Channel
    963
    Satellite Tracked
    GPS L1CA/L1P/L1C/L2P/L2C/L5
    GLONASS G1, G2, G3
    Galileo E1, E5a, E5b, ALTBOC, E6
    QZSS L1, L2 L5,
    BeiDou B1I, B2I, B3I, B1C, B2a, B2b, ACEBOC
    SBAS Ll, L5
    Update rate
    5 Hz, up to 50 Hz
    Performance Specifications
    Signal Reacquisition
    < 1 sec
    Hot Start
    < 10 sec
    Initialization Reliability
    > 99.9%
    Memory
    8 GB
    IMU
    0~60°
    Tilt compensation accuracy
    10mm+0.7mm/°tilt (accuracy within 30°<2.5cm)
    Static Accuracy
    Horizontal:3mm + 1ppm
    Vertical:5 mm + 1 ppm
    RTK Accuracy
    Horizontal:8 mm + 1 ppm
    Vertical:15 mm + 1 ppm
    Code Differential
    Horizontal:0.4 m
    SBAS Accuracy
    Horizontal:0.8 m
    Communication
    7-pin
    Connect to external power and radio
    USB
    For charging and data transmission
    Cellular
    Global 4G
    Bluetooth
    V4.1
    WIFI
    802.11 ac/n/b/g/n
    WebUI
    Update firmware, manage settings and
    status, download data
    Date formats
    CNR input and out put
    RTCM 2.x, RTCM 3.x input and output
    NMEA 0183 output
    HCN, HRC and RINEX 2.11, RINEX 3.02
    NTRIP Client, NTRIP Caster
    Electronic Bubble
    Support
    Dimensions
    119 mm*119 mm * 85mm,0.73kg
    Shock
    Survive a 2 m pole drop on concrete floor 1.2 m free drop
    interface
    1 USB-TypeC interface, support charging, power supply, data download
    SIM Card
    NANO SIM
    Cellular
    Global 4G
    Bluetooth
    V2.1+EDR / V4.1 Dual Mode, Class 2
    WIFI
    802.11 ac/n/b/g/n
    WebUI
    Update firmware, manage settings and status, download data
    Electronic Bubble
    Support
    Environment
    Dustproof&Waterproof
    IP67 (Customizable IP68)
    Humidity
    95% non-condense
    Power Supply
    Battery
    Rechargeable, built-in Lithium-ion battery,7.2 V - 6800mAh
    Voltage
    9~28 V DC external power input
    Working Time
    Up to 15 hours
    Internal Radio
    Protocol
    CHC, Transparent, TT450
    Radio
    RK radio, Built-in high-frequency 450-470MHz

    Certifications
