Unistrong G970II GPS GNSS RTK Receiver Base And Rover Surveying Instrument

Ask Lasest Price
Brand Name :	Unistrong
Model Number :	G970ii
Price :	$3,050.00
Payment Terms :	L/C, T/T
Supply Ability :	1 ~ 30 day
Delivery Time :	30 work day

Add to Cart

Product Details
Company Profile

Unistrong G970II GPS GNSS RTK Receiver Base And Rover Surveying Instrument

Unistrong G970II GPS Gnss Rtk Receiver Surveying Instrument

내장 블루투스 모듈 새로운 RTK GPS 휴대용 핸드 헬드 고정밀 모듈 안테나 GNSS 수신기 USB 레벨 NMEA0183 ...

Technical Specificat

Product model		G970II
GNSS	Channels	800 channels
GNSS	Satellite Signals	GPS: L1C/A,L1C,L1P,L2C,L2P,L5; GLONASS:G1P1,G1OC,G2OC,G2P2,G3OC BDS: B1I, B2I, B3I, B1C, B2a, B2b, ACEBOC; Galileo: E1BC, E5a, E5b, ALTBOC, E6 QZSS: L1C/A, L1C, L2C, L5, LEX; SBAS: L1, L5; IRNSS: L5; L-Band
Accuracy	Static	H: 2.5mm±1ppm,V: 5mm±1ppm
	RTK	H: 8mm±1ppm,V: 15mm±1ppm
	DGNSS	<0.5m
	ATLAS H10	8cm
	Initialization Time	8s
	Initialization Reliable	99.9%
System	OS	Linux
	Memory	8GB,support expandable MicroSD
	Wi-Fi	802.11 b/g/n
	Bluetooth	V2.1+EDR/V4.1Dual, Class2
	E-Bubble	Support
	IMU Tilt Survey	Fusion positioning, 400Hz refresh rate, 2cm (@60°Tilt degree)
	Audio	support TTS audio broadcast
Datalink	UHF radio	T/Rx Internal Radio, 1W/2W adjustable, 410-470MHz
	Radio protocol	Support GeoTalk, SATEL, PCC-GMSK, TrimTalk, TrimMark, South, Hi-Target
	Network	4G-LTE, TE-SCDMA, CDMA(EVDO 2000), WCDMA, GSM(GPRS)
	Reference outputs	RTCM2.3, RTCM3.2, CMR,CMR+,ROX
Physical	Interface	1TNC Radio Antenna, 15Pin(Power & RS232),1*7Pin (USB 81 RS232)
	Button	1 Power Button
	Indication Light	4 Indication Lights
	Size	Φ156mm×H76mm
	Weight	1.2kg
Power supply	Battery capacity	7.2V, 24.5Wh(standard two batteries)
	Life Timer	Static Survey: 15 hours, Rover RTK survey: 12h
	External power source	DC 9-18V, with overvoltage protection
Environment	Work Temperature	-35ºC~+65ºC
	Storage Temperature	-55ºC~+85ºC
	Waterproof & dustproof	IP68
	Humidity	100% anti-condensation

REAL PRODUCT PHOTO

Unistrong G970II GPS GNSS RTK Receiver Base And Rover Surveying Instrument

Exhibition

Certifications

Company Profile

FAQ

1. who are we?
We are based in sichuan, China, start from 2016,sell to Africa(30.00%),Southeast Asia(16.00%),Mid East(11.00%),Eastern
Asia(10.00%),South America(10.00%),Central America(5.00%),South Asia(5.00%),Southern Europe(5.00%),North America(4.00%),Eastern
Europe(4.00%). There are total about 11-20 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
GNSS RTK,Total station,Level,Survey accessory,laser rangefinder

4. why should you buy from us not from other suppliers?
1.More than 20 years of experience in the trade field. 2.All products will have been strictly quality checked in factory before
sending out and all products have one year warranty.

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
