CHENGDU JIEBO TECHNOLOGY CO.,LTD Main categories: GPS measuring instrument,total station,Level,Theodolite,Measuring accessories
2 Years
| Ask Lasest Price | |
| Brand Name : | STONEX |
| Model Number : | S6II/S980 |
| Price : | $3,400.00 |
| Payment Terms : | L/C, T/T |
| Supply Ability : | 1 ~ 30 day |
| Delivery Time : | 30 work day |
International Version Stonex S6II/S980 GPS GNSS With Google Function&Updatable Surpad Software Receiver RTK
Product Detail
| Tracking | |
| Board: | Novatel OEM729 |
| Channels: | 1408 |
| GPS: | L1C/A, L1C, L1P, L2C, L2P, L5 |
| GLONASS: | L1C/A, L1P, L2C/A, L2P, L3 |
| Galileo: | E1, E5a, E5b, ALTBOC, E6 |
| BeiDou: | B1, B2, B3, ACEBOC |
| QZSS: | L1 C/A, L1C, L2C, L5, L6 |
| IRNSS: | L5 |
| SBAS: | L1, L5 |
| Update Rate: | 5 Hz |
| Operating System: | Linux |
| Memory: | 32 GB |
| Positioning | |
| Static Survey: | 3 mm + 0.1 ppm RMS (Horizontal) |
| 3.5 mm + 0.4 ppm RMS (Vertical) | |
| RTK (< 30 Km): | 8 mm + 1 ppm RMS (Horizontal) |
| 15 mm + 1 ppm RMS (Vertical) | |
| Code Differential: | 0.40 m RMS |
| SBAS Accuracy: | 0.60 m |
| Internal UHF Radio | |
| Model: | TRM 501 |
| Type: | Tx – Rx |
| Frequency Range: | 410 – 470 MHz |
| 902.4 – 928 MHz | |
| Channel Spacing: | 12.5 KHz / 25 KHz |
| Transmission Power: | 2-5 watt |
| Maximum Range: | > 5 km with 2 watt |
| > 10 Km with 5 watt | |
| Physical | |
| Size: | Φ151mm x 94.5mm |
| Weight: | 1.50 Kg |
| Operating Temperature: | -40 °C to +65 °C |
| Storage Temperature: | -40 °C to +80 °C |
| Waterproof/Dustproof: | IP67 |
| Shock Resistance: | Designed to endure a 2 m pole drop onto a concrete floor with no damage |
| Vibration: | Vibration resistant |
| Power Supply | |
| Battery: | Rechargeable 7.2 V – 13.600 mAh |
| Voltage: | 9 to 28 V DC external power input with over-voltage protection (5 pins Lemo) |
| Working Time: | Up to 10 hours |
| Charge Time: | Typically 4 hours |
Product Display
FAQ
1. who are we?
We are based in sichuan, China, start from 2016,sell to Africa(30.00%),Southeast Asia(16.00%),Mid East(11.00%),Eastern
Asia(10.00%),South America(10.00%),Central America(5.00%),South Asia(5.00%),Southern Europe(5.00%),North America(4.00%),Eastern
Europe(4.00%). There are total about 11-20 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
GNSS RTK,Total station,Level,Survey accessory,laser rangefinder
4. why should you buy from us not from other suppliers?
1.More than 20 years of experience in the trade field. 2.All products will have been strictly quality checked in factory before
sending out and all products have one year warranty.
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
|
|
